物理特性/Physical Characteristics

尺寸 Dimensions:

96.7mm x 104mm x 145mm

重量 Weight:

297.5g

電壓 Voltage:

3.3~5VDC

電流Current:

450mA (Operating)

性能指標/Performance Characteristics

傳感器像素 Image (Pixels):

1280 pixels (H)x 800 pixels (V)

光源 Light Source:

紅光LED

視場角 Field of View:

50°

旋轉/傾斜/偏轉 Roll / Pitch / Yaw:

58°（水平） , 45°（垂直）

打印對比度Print Contrast:

20% minimum reflective difference

接口支持 Interfaces Supported:

USB,RS232

運動容差Motion Tolerances:

>2m/s 解碼能力

解碼能力/Symbology Decode Capability

一維條碼/1-D:

Codabar, Code 11, Code 39, Code 93, Code 128/EAN128, EAN.UCC Composite, Interleaved 2 of 5,MSI Code, Planet, Plessey Code, Postnet, RSS, Standard 2 of 5, Telepen, UPC/EAN, etc

二維條碼/2-D:

PDF417, QR code, Matrix 2 of 5, MicroPDF417, Australian Post, Canada Post, Japan Post, MaxiCode, Codablock, Aztec, Dutch Post, TLC 39,DataMatrix, etc.

條碼精度Minimum Resolution

≥3.9 mil

用戶環(huán)境參數(shù)/User Environment

工作溫度 Operating Temperature:

-20°C to 60°C

存儲溫度 Storage Temperature:

-30°C to 70°C

濕度 Humidity:

5% to 95% relative hum idity,non-condensing

抗震性 Shock Specifications:

8 G r.m.s., from 10 to 500 Hz, 2 hours per axis, 3 axes

環(huán)境光免疫 Ambient Light Immunity:

0-100,000 Lux.

解碼范圍/Decode Ranges

5 mil (Code 39)

0mm-60mm

13 mil (code39)

0mm-170mm

15 mil (PDF417)

0mm-60mm

13 mil (UPC-A)

0mm-150mm

30 mil (QR Code)

0mm-130mm

Performance may be impacted by bar code quality and environmental conditions
